HIKRAYIN ISD-SMW1701S Millimeter wave body scanner is a series of security body inspection systems based on the characteristics of millimeter wave and the principle of SAR (synthetic aperture radar). The system can quickly generate a 3D holographic image of the scanner body, identify and locate various metallic and non-metallic suspicious items concealed and indicate on a cartoon manikin without any contact to the body. This system is ideally for security scenarios like airports, customs, prisons, etc.
The person being scanned stands naturally with arms hanging down and slightly apart, pauses briefly, and feels at ease. The millimeter wave is reflected by the skin and cannot penetrate the body with no ionized radiation. So it is totally safe for children, pregnant women, people with stent and other electrical medical devices, and the elderly.
Detection resolution can reach 2 mm. Location and shape of the concealed items can be displayed with high accuracy. With the deep learning intelligent detection algorithm, the system can detect various of metallic/non-metallic items, such as guns, knives, tinder, explosives, narcotics, cash, luxury goods, etc.
A full scan can be completed in 2 seconds, with a throughput rate of up to 700 people per hour.
The operator performs the scanning according to the sex of the person being inspected. Only cartoon images are generated to show the alarm area and displayed on the local screen together with the alarm positions.
| Millimeter Wave Body Scanner | |
|---|---|
| Dimensions | 2436 mm (H) × 1325 mm (W) × 1500 mm (L) |
| Tunnel Size | 2150 mm (H) × 750 mm (W) × 1275 mm (L) |
Yes. Unlike conventional metal detectors, a millimeter-wave body scanner can detect both metallic and non-metallic objects concealed under clothing. Because detection is based on advanced image analysis rather than material type, it can identify a wider range of potential threats.
A millimeter-wave body scanner emits low-power millimeter-wave signals toward the person being screened. The reflected signals are used to reconstruct a three-dimensional image of the body surface, and AI-powered detection algorithms automatically identify suspicious objects concealed under clothing. The inspection is fast, non-contact, and does not require physical searches in most cases.
Yes. Millimeter-wave technology uses non-ionizing electromagnetic waves, making it safe for routine security screening. The transmitted power is extremely low—significantly lower than that of many everyday wireless devices—and the signals are reflected by the surface of the skin rather than penetrating the body. This makes the technology safe for passengers, operators, and other users.
