Designed for the entire electronics manufacturing process—including SMT assembly, PCB inspection, semiconductor packaging, and electronic component quality control—this solution provides comprehensive X-ray inspection throughout production. Powered by high-resolution X-ray imaging, AI-driven defect recognition, 2D/3D inspection technologies, and intelligent data analysis, it enables precise detection of solder joints, internal structures, and hidden defects while supporting automated quality control.
The solution improves inspection accuracy, reduces false calls and manual intervention, and enhances manufacturing efficiency and product reliability. It is ideal for PCB, semiconductor, consumer electronics, automotive electronics, and other high-precision electronic manufacturing industries.
